Duravia

Model: Duravia 3030
Price: On request
Lead time: To be confirmed at time of order
Intended device approval: FNPII or FNPII MCC

Intended training credits:

• Night rating training
• Instrument Flight Training (IFR) training
• Instructor patter
• Scenario based training modules
• IFR renewal and testing
• Training toward initial twin engine rating
• IFR Recency
• RNAV approval for GPS based approach training

General features:

• High fidelity cockpit layout
• Cockpit layout for the Seneca, Seminole, custom or generic aircraft
• Height and position adjustable Pilot and Co-Pilot seats
• Stand alone modular product to be installed into appropriate simulator room

Flight models supported:

• Single engine with fixed gear and fixed pitch
• Single engine with retractable gear and variable pitch
• Twin engine with retractable gear and variable pitch
• Custom flight model and QTG development available

Cockpit features:

• Dual Controls: Yoke and Rudder with proportional toe brakes
• Dynamic Control Loading (FORCE FEEDBACK)
• Dual "T" Panel including ASI, AH, FD, ALT, Turn Slip, HSI/ DI, ADF, OBS
• Engine instruments (Piston): Manifold pressure indicator, RPM, Fuel Flow, EGT
• Fuel quantity, oil pressure, oil and cylinder head temperature instruments
• Suction pressure and ammeter instruments
• Electric Trim
• Trim console: Elevator trim wheel and rudder trim wheel
• Throttle options:twin engine quadrant and/or single vernier controls
• Cowl flap control
• Park Brake control
• Landing Gear Panel: Gear lever and gear indicators
• Emergency landing gear system
• Flap lever control
• Flap indicator
• Annunciator Panel
• Analog "wet" compass
• Real aircraft circuit breakers that can "pop" from instructor's station control panel

Additional features for MCC:

• Generic twin turbine flight model and QTG
• Engine instruments: turbine instruments for MCC
• Generic simulated pressurisation system
• Pilot and Co Pilot oxygen masks
• Airframe icing control panel

Avionics:

• GPS GNS 530 with TAWS based on the Garmin trainer logic
• NAVCOM2, DME, Transponder, ADF
• Autopilot based on the KFC275 logic
• Up to date NAV AID database. Updates available every 3 months
• Real World GPS database available with 13 cycles per year

Visual system:

• Warped or planar 3 or 5 channel visual system
• Visual system offers 180° to 240° horizontal FOV and up to 60° vertical FOV
• Photo real commercial scenery available
• Photo real commercial scenery for South Africa from NMG

Instructors operating system:

• Advanced Instructor Operating System (IOS)
• Standard and custom malfunctions available
• QTG data and QTG Software
• User and Maintenance Manuals

QTG System:

• Auto QTG system - QTGs can be run at the touch of a button
• Batch QTGs can be run from AutoQTG Package
• QTG results browser based to form part of future E-QTG system

Warranty:

• New machines come with a 3 year Warranty

Don't expect the usual.
Our machines come with a 3 year Warranty.
